LAN ports:
4 x RJ45 ( 4 x PoE (802.3af/at) ),
1 x RJ45 (Uplink)
Management:
LED diodes: Power, Link/Act, PoE, PoE Max, 5 Uplink
Transmission speed:
10 / 100 / 1000 Mbps - 4 LAN & PoE ports,
10 / 100 / 1000 Mbps - 1 RJ45 (Uplink) port
Maximal output power: 30 W / port PoE
Maximal total power: 45 W
Switching capacity: 10 Gb/s
Forwarding rate: 7.44 Mpps
MAC addresses table: 2k
Default IP address: 10.180.190.200
Default admin user / password: admin / -
Operation modes:
Long Range - 300 m, 10 Mbps - 1 ... 4 ports
Port Isolation - 1 ... 4 ports
Watchdog PoE - 1 ... 4 ports
Main features:
Switch is web managed
Configuration and management from the iVMS-4200 application
Hik-Central Pro support
HPP - Hik-Partner Pro support - View topology and network status, Remote update of software, Remote configuration
Port Isolation - Port isolation
PoE Watchdog mode - monitoring of the ports that power PoE devices and automatic restart by cutting off the power supply when an unresponsive device is detected
Static link aggregation - Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection
Loop Protection - IEEE 802.1d, IEEE 802.1w, Spanning Tree STP/RSTP
DHCP client
IEEE 802.1Q VLAN - IEEE 802.1Q standard support, up to 32 VLAN groups and 1 ... 4094 VIDs
Cable test
Compliance with the LLDP protocol
SNMPv1/v2c
Port mirroring function
Power supply PoE : Support for Endspan mode 1-2(-), 3-6(+)
RESET button
Possibility to mount to the wall
Certificates: CE, RoHS, WEEE
Protections: Overvoltage 6 kV - PoE ports
Housing: Metal
Color: Graphite
Power supply: 54 V DC / 0.92 A (power adapter included)
Power consumption: max. 50 W
Operation temp: 0 °C ... 40 °C
Weight: 0.222 kg
Dimensions: 121 x 83 x 28 mm
Manufacturer / Brand: Hikvision
